CEFS-RA21-Q17A-4U
采用Q170芯片组
支持双千兆网口
支持VGA、DVI-D、DP++三屏异显
内置PCI,PCIe插槽，支持多种模块扩展
抗震动磁盘架设计，可支持1个5.25寸光驱、2个2.5"SSD、3个3.5"HDD硬盘
前部可访问 USB接口，更易于数据传输
海岸线上的USB端口支持Ennoconn USB SR Pro
|
■ 规格 Specification |
|
||
|
系统 System |
|||
|
处理器 Processor |
Intel® 6th/7th Gen Core ™ i7/i5/i3/Pentium®/Celeron® Processor, LGA1151 Socket,TDP up to 95W |
||
|
芯片 Chipset |
Intel® Q170 Chipset |
||
|
内存 Memory |
Dual Channel, 4 x U-DIMM Slot, DDR4 2133/2400MHz, up to 64GB |
||
|
存储 Storage |
4 x SATA3.0, 1 x M.2 2242/2280 (SATA3.0/PCIe3.0 supported) |
||
|
图形 Graphics |
Intel® HD Graphics, triple display |
||
|
操作系统 OS |
6th Gen CPU : Windows7/8/10, Linux |
||
|
外部接口 External I/O |
|||
|
网口 Ethernet |
1 x Intel® i219-LM GbE, 1 x Intel® i211-AT (10/100/1000 Mbps) |
||
|
显示 Video |
1 x DVI-D: max resolution up to 1920 x 1200@60Hz |
||
|
串口 COM |
1xRS232/422/485(with auto flow control) |
||
|
USB |
6 x USB 3.0, 4 x USB 2.0 (Rear USB ports support Ennoconn USB SR Pro) |
||
|
按钮 Button |
1 x Power Button, 1 x Reset Button |
||
|
指示灯 LED |
1 x Power LED, 1 x HDD LED |
||
|
内部接口 Internal I/O |
|||
|
扩展接口 Expansion |
2 x PCIe X16 (Gen3, 1 x 16 or 2 x 8 link), 3 x PCIe X4 (X4 link) , 2 x PCI |
||
|
USB |
3 x USB2.0 (Type-A share USB signal with one USB2.0) |
||
|
风扇 FAN |
1 x CPU Fan, 2 x System Fan |
||
|
GPIO |
1 x 16-bit GPIO |
||
|
串口 COM |
1 x RS232/422/485, 2 x RS232/485, 2 x RS232 |
||
|
PS/2 |
1 x PS/2 pinheader (keyboard and mouse) |
||
|
LPT |
1 x LPT |
||
|
信赖平台模块 TPM |
Nuvoton TPM1.2 |
||
|
环境 Environmental |
|||
|
操作温度 Operating Temp. |
0℃ ~ 40℃ |
||
|
存储温度 Storage Temp. |
-20℃ ~ 60℃ |
||
|
湿度 Relative Humidity |
5% ~ 95%, 非凝结状态 Non-condensing |
||
|
随机振动 Random Vibration |
5~500Hz, 1Grms (HDD)operation |
||
|
正弦振动 Sine Vibration |
5~500Hz, 2G Non-operation |
||
|
机械冲击 Shock |
10G @ 11ms operation |
||
|
电源 Power |
|||
|
电源输入 Power Input |
100~240V (AC) |
||
|
电源功耗 Power Watt |
300W |
||
|
机构 Mechanical |
|||
|
外观 Housing |
SECC 1.2mm | ||
|
尺寸 Dimension |
480.8(W) x 177(H) x 478.6(D) mm | ||
|
重量 Weight |
15kg ( 约 ) |
||
|
安装方式 Mounting |
机柜式 (Rack-Mount) |
||
|
认证 Certification |
|||
|
安规认证 Safety Certification |
CCC&CE&FCC | ||
|
■ 订购清单 Order List |
|||
|
标配 |
型号 Model |
描述 Description |
|
|
35074KN00-704-G |
AC Power Cable, 1500mm, +70/-0mm, I-SHENG, T |
||
|
35091QW00-0R3-G |
S-ATA Signal Cable Assembly,400mm,+/-20mm0mm |
||
|
选配 |
型号 Model |
描述 Description |
|
|
86011CG00-01T-G |
Desktop SPS,500W PFC,HUNTKEY,HK601-11PP | ||
|
860117D00-289-G |
Desktop SPS, 650W Non PFC, LITEON, PS-8651- |
||
| 86011BJ00-01T-G | PC SPS,750W,HUNTKEY,HK850-11PP | ||
| 86020E400-66A-G | Server SPS,850W 1U,GREATWALL,GW-ATX850BL | ||
| 86020GK00-66A-G | SPS,1000W 1U,GREATWALL,GW-EPS1000DA(90+) | ||
|
351061R00-JTU-G |
LPT cable with bracket, 450mm |
||
|
351061S00-JTU-G |
GPIO cable with bracket, 350mm |
||
| 35106BR00-38L-G |
1 to 2 USB Cable with bracket, 300mm+/-15mm |
||
| 351091T00-0R3-G | Com*1 Bracket Cable,400mm,+/-10mm,KASIJI | ||
| 351091S00-0R3-G | Com*2 Bracket Cable,400mm,+/-10mm,KASIJI | ||
