■ 规格 Specification
|
|
|
系统 System
|
|
处理器 Processor
|
Intel® 10th Gen Core ™ i9/i7/i5/i3/Xeon®Processor, LGA1200, TDP up to 95W
|
|
芯片 Chipset
|
Intel® W480E
|
|
内存 Memory
|
4 x DDR4 ECC/Non-ECC 2400/2666/2933 MHz U-DIMM Slot, up to 128GB(Core ™ i5/i7/i9 only support Non-ECC)
|
|
图形 Graphics
|
Intel® UHD Graphics 630
|
|
存储 Storage
|
4 x SATA 3.0, 1 x M.2 (SATA3.0/PCIe 3.0 x 4) 2242/2280
|
|
操作系统 OS
|
Windows 10, Linux
|
|
看门狗 Watchdog Timer
|
System Reset, Programmable via software from 1 to 255 seconds
|
|
信赖平台模块 TPM
|
Nuvoton TPM2.0(optional, need MOQ)
|
|
外部接口 External I/O
|
|
网口 Ethernet
|
1 x Intel® i219-LM GbE, 2 x Intel® i211-AT/i210-AT (10/100/1000 Mbps)
|
|
显示 Video
|
1 x DVI-D: max resolution up to 1920 x 1200 @ 60Hz
1 x VGA: max resolution up to 1920 x 1200 @ 60Hz
1 x DP: max resolution up to 4096 x 2304 @ 60Hz
|
|
音频 Audio
|
1 x Line-out, Mic-in
|
|
串口 COM
|
1 x RS232/422/485 ( with auto flow control )
|
|
USB
|
6 x USB3.2 Gen1, 2 x USB2.0
|
|
按钮 Button
|
1 x Power Button, 1 x Reset Button
|
|
指示灯 LED
|
1 x Power LED, 1 x HDD LED
|
|
内部接口 Internal I/O
|
|
扩展Expansion
|
2 x PCIe3.0 X16 (1 x 16 or 2 x 8 link), 3 x PCIe X4 (X4 link), 2 x PCI
|
|
USB
|
6 x USB2.0 (1 x Type-A)
|
|
风扇 FAN
|
1 x CPU Fan, 2 x System Fan
|
|
GPIO
|
1 x 16-bit GPIO
|
|
串口 COM
|
1 x RS232/422/485 (with auto flow control), 2 x RS232/485, 2 x RS232
|
|
LPT
|
1 x LPT
|
|
PS/2
|
1 x PS/2 (keyboard and mouse)
|
|
环境 Environmental
|
|
操作温度 Operating Temp.
|
0°C - 40°C
|
|
存储温度 Storage Temp.
|
-20°C - 60°C
|
|
湿度 Relative Humidity
|
5% ~ 95%, 非凝结状态 Non-condensing
|
|
随机振动 Random Vibration
|
5~500Hz, 1Grms (HDD)operation
|
|
正弦振动 Sine Vibration
|
5~500Hz, 2G Non-operation
|
|
机械冲击 Shock
|
10G @ 11ms operation
|
|
电源 Power
|
|
电源输入 Power Input
|
100~240V(AC)
|
|
电源功耗 Power Watt
|
300W
|
|
机构 Mechanical
|
|
外观 Housing
|
SGCC
|
|
尺寸 Dimension
|
200(L) x 430(W) x 330(H)mm
|
|
重量 Weight
|
9.96kg( 约 )
|
|
安装方式 Mounting
|
壁挂式(Wallmount)
|
|
认证 Certification
|
|
安规认证 Certification
|
CCC
|
|
■ 订购清单 Order List
|
|
|
型号
|
配置信息
|
|
标配
Standard
|
35074KN00-704-G
|
AC Power Cable,1500mm,+70/-0mm,I-SHENG,T
|
|
35091AW00-JTU-G
|
SATA Signal Cable Assembly,400mm,+/-20mm
|
|
选配
Optional
|
860117E00-289-G
|
Desktop SPS,500W,LITEON,G,PS-8501-2EN
|
|
860117D00-289-G
|
Desktop SPS,650W Non PFC,LITEON,PS-8651-
|
|
86020E400-66A-G
|
Server SPS,850W 1U,GREATWALL,GW-ATX850BL
|
|
351061R00-JTU-G
|
LPT cable with bracket, 450mm
|
|
351061S00-JTU-G
|
GPIO cable with bracket,350mm
|
|
35106BR00-38L-G
|
1 to 2 USB Cable with bracket,300mm+/-15mm
|
|
35106WJ00-38L-G
|
COM2,COM Cable witht Bracket,400+/-10mm
|
|
35107VA00-38L-G
|
PS2 KBMS /1*6Pin,400mm,+/-10mm,VSO,SR4H05621
|
|
35106WK00-38L-G
|
COM3~4/COM5~6,COM Cable with Bracket,400+/-10mm
|
